Ship Electric Push Control System
CY-ST-22-200
The marine electric thruster control system, with a rated power ranging from 22 to 200 kW, is suitable for various large vessels and is applied in scenarios such as offshore berthing, precise positioning, and port maneuvering.
Product Specifications
Product Information
Product Name
Ship Electric Push Control System
Product Model
CY-ST-22-200
rated power
22-200kW
Applicable ship types
Various types of large ships
Application Scenarios
Offshore berthing, precise positioning, and port maneuvering of large ships
Core parameters
thrust
5-70kN
propeller diameter
440-1400mm
response time
<50ms
propeller
4-blade fixed-pitch propeller
Material
Cu1 nickel-aluminum bronze
Control method
variable frequency speed control
Installation Method
tunnel-type
turn
bidirectional thrust
overload capacity
150% per minute
Other parameters
Core Highlights
Precise control, rapid response, low noise, energy-saving and environmental protection
Motor type
Permanent magnet synchronous motor
Rated Voltage
AC 400V
Cooling method
Water cooling + oil cooling
Protection Rating
IP68
System Weight
280-850kg
Noise level
<68dB
Battery parameters
Independent power supply system
Operating Temperature
-15℃-55℃
Certification standard
CCS, LR, BV certification
Design life
40,000 hours
